Camera Case Type

Bullet;Dome

Image Sensor

1/2.8" Progressive Scan CMOS

Min. Illumination

0.028 Lux

Shutter Speed

1/3 s to 1/100,000 s

Day &Night

IR cut filter

WDR

DWDR

Angle Adjustment

Bullet: Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360° Dome: Pan: 0° to 355°, tilt: 0° to 75°

Protection Level

IP67

Material

Bullet: Front cover: metal, back cover & bracket: plastic Dome: Front cover: plastic, back cover & bracket: metal

Wi-Fi Support

No

Focal Length

2.8 mm

Aperture

F2.0

Focus

Fixed

FOV

Horizontal FOV: 114.8°, vertical FOV: 62°, diagonal FOV: 135.5°

Lens Mount

M12

IR Range

Up to 30 m

Video Compression

H.265+;H.265;H.264+;H.264;MJPEG

H.264 Type

Main Profile/High Profile/Baseline Profile

H.264+

Main Profile

H.265 Type

Main Profile

H.265+

Main Profile

Video Bit Rate

32 Kbps to 8 Mbps

Max. Resolution

2MP

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream

50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)

Image Setting

Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

Day/Night Switch

Auto/Scheduled/Day/Night

Alarm Trigger

Motion detection, video tampering alarm, illegal login

Protocols

TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark

Client

iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500

Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

On-board Storage

N/A

Audio I/O

No

Video Out

No

Alarm I/O

No

Reset Button

No

Power Supply

12 VDC ± 25%, Φ 5.5 mm coaxial plug power, or PoE (802.3af, class 3)

Consumption

Bullet: 12 VDC, 0.3 A, Max: 3.5 W, or PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W Dome: 12 VDC, 0.4 A, Max: 5 W, or PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W

Working Temperature

-30 °C to 60 °C (-22 °F to 140 °F)

Working Humidity

95% or less (non-condensing)

Dimension (W × D × H)

Bullet: Ø 70 mm × 172.7mm (2.8" × 6.8") Dome: Ø 111 mm × 82.4 mm (4.4" × 3.2")

Weight

Bullet: Approx. 270 g (0.6 lb) Dome: Approx. 400 g (0.9 lb)

IP Video Input

4-ch

Incoming/Outgoing Bandwidth

40 Mbps/60 Mbps

HDMI/VGA Output

1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Decoding Format

H.265+;H.265;H.264+;H.264

Capability

2-ch@1080p/1-ch@4 MP

Network Interface

1, RJ45 10/100M Ethernet interface

Network Protocol

IPv6, UPnP™, NTP, SADP, DHCP

Remote Connection

16

Interface

4-ch

Power

≤ 36 W

Standard

IEEE 802.3 af/at

SATA

1

Capacity

Up to 6 TB capacity for each disk

USB Interface

Rear panel: 2 × USB 2.0

Alarm In/Out

No

Power Supply

48 VDC

Consumption (without HDD and PoE off)

≤ 10 W

Working Temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity

10% to 90%

Dimension (W × D × H)

265 × 225 × 48 mm (10.4" × 8.9" × 1.9")

Weight (without hard disk)

≤ 1 kg (2.2 lb)

Accessories

Power: 1 power cable Network cable: 4 × 18.3 m (60 ft) video and power cable HDMI cable: 1 HDMI cable

Hard Drive

No

Certification

FCC, CE

Weight (with package)

≤ 6.5 kg (14.3 lb)
