Power supply

12 VDC+10 %, 900 mA (startup current), 100 mA (standby)

Working temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working humidity

0 to 95 % (relative humidity)

Dimensions

Lock Body (L × W × H): 205×35×40mm (8.07 × 1.38 × 1.57") Armature Plate (L×W×H): 90 × 25 × 2 mm (3.54 × 0.98 × 0.07") Bolt: 16 mm × 16 mm (0.63 × 0.63")

Material

Bolt: polished and brushed stainless steel

Thrust

800 kg

Door type

Wooden door, glass door, metal door, fireproof door

Signal output

Signal output NC, COM contact of door status

Magnetic induction distance

8 mm (0.31")

Delay duration

0/3/6/9 s Optional
