Cameras

256

Video Intercom Devices

64

Alarm Inputs

64

Alarm Outputs

64

ANPR Cameras

32

Facial Recognition Cameras

16

Security Radars and Radar PTZ Cameras

16

Recording Server

16

People Counting Cameras

16

Heat Map Cameras

16

Thermal Cameras

16

Queue Management Cameras

16

Recording Schedule

64

Recording Schedule Template

32

Event and Alarm Rules

1,500

Storage of Events or Alarms without Pictures

100/s

Events or Alarms Sent to Clients

15/s 32 Clients/s

Picture Storage

20/s *Including event/alarm pictures, face pictures, and vehicle pictures.

Data Retention Period

Stored for 3 Years

Concurrent Accesses via Web Clients, Control Clients, and OpenAPI Clients

32

Concurrent Accesses via Mobile Clients and OpenAPI Clients

32

Users

256

Roles

32

Vehicle Lists

100

Vehicles per Vehicle List

5,000

Lanes

8

Vehicle Passing Frequency in Each Lane

1 Vehicle/s

Persons with Profiles for Face Comparison

10,000

Face Comparison Groups

16

Persons in One Face Comparison Group

1,000

Persons with Credentials for Access Control

10,000

Total Credentials (Card + Fingerprint)

50,000

Cards

50,000

Fingerprints

40,000

Profile Pictures

10,000

Access Points (Doors + Outdoor Station)

128

Access Levels

256

Persons for Time and Attendance

10,000

Shift Schedules

128

Major Leave Types

64

Minor Leave Types of One Major Type

128

Decoding Devices

32

Smart Walls

32

Views Auto-Switched Simultaneously

32

Main Processor

Quad-Core Intel® Xeon® Processor E3 V5 Series

Memory

16GB DDR4. ECC parity. Extendable up to 64 GB

System Bandwidth

Multi-address/net fault-tolerance mode: 768 Mbps; Load balancing mode: 1,000 Mbps

Number of Storage Channels

256

HDMI 1 Output

1024 × 768/60 Hz

HDMI 2 Output

1024 × 768/60 Hz

VGA Output

1024 × 768/60 Hz

Video Output Mode

HDMI1/HDMI2/VGA simultaneous output

Audio Output

1-ch, RCA (Linear, 1 KΩ)

Audio Input

1-ch, RCA (2.0 Vp-p, 1 KΩ)

Network Interface

4 × RJ45 10M/100M/1000M self-adaptive Ethernet interface

RAID Type

RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60, JBOD

SATA

16 SATA interfaces supporting hot-swapping (except the HDD at the first slot which contains the system disk)

eSATA

1 eSATA interface

Capacity

Up to 10 TB capacity for each disk

USB Interface

Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0

Alarm In/Out

16/8

Extension Board

The extension board is optional to support. It has four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, 32 alarm inputs, and 16 alarm outputs.

Consumption

≤ 140 W (without HDD)

Working Temperature

0 °C to 50 °C (32 °F to 122 °F);

Working Humidity

10% to 90% RH (no freezing and no condensation)

Chassis

3U

Dimension (W × D × H)

446 × 495 × 133 mm (17.6 × 19.5 × 5.2 inch)

Weight

≤ 17 kg (37.5 lb.)
