Face Recognition Terminal/Audio
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Volume adjustment
Adjust via device or client
Face Recognition Terminal/Authentication
Card type
M1 card
Card reading distance
0 to 3 cm
Card reading duration
< 1 s
Face recognition duration
< 0.2 s
Face recognition distance
0.3 to 1.5 m
Face Recognition Terminal/Camera
Pixel
2 MP
WDR
Support
Lens
2
Video standard
PAL (Default) and NTSC
Face Recognition Terminal/Capacity
Card capacity
1500
Face capacity
1500
Event capacity
150000
Face Recognition Terminal/Function
Face antispoofing
Support
Live view
Supports live view on the platform, H.264
Face recognition
Supports face recognition in low illumination
Access control management
Support multiple authentication methods
Face Recognition Terminal/General
Protection level
IP65
Power supply
12 VDC, 2A
Working temperature
-30 °C to 60 °C (-22 °F to 140 °F)
Working humidity
0 to 90% (No condensing)
Face Recognition Terminal/Interfaces
Network interface
1, RJ45
RS-486
1
Wiegand
Wiegand 26 and Wiegand 34
Lock output
1
Exit button
1
Door contact input
1
Power interface
1
TAMPER switch
1
USB
1, USB 2.0
Face Recognition Terminal/Network
Wired network
10/100/1000 Mbps self-adaptive
Communication protocol
ISUP 5.0
Face Recognition Terminal/Screen
Size
4.3-inch
Resolution
800 × 480
Operation method
Capacitive touch screen
Face Recognition Terminal/System parameters
Operation system
Embedded Linux operation system
Indoor station/System parameters
Operation system
Embedded Linux operation system
Memory
128 MB
Flash
32 MB
Indoor station/Display parameters
Display screen
7-inch colorful IPS LCD
Display resolution
1024 × 600
Operation method
Capacitive touch screen, physical button
Indoor station/Audio parameters
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Audio quality
Noise suppression and echo cancellation
Audio compression standard
G.711 U
Audio compression Rate
64 Kbps
Indoor station/Network parameters
Wired network
10/100 Mbps self-adaptive
Wireless network
Wi-Fi 802.11 b/g/n
Protocol
TCP/IP, SIP, RTSP
Network interface
1 RJ-45 10/100 Mbps self-adaptive
Alarm input
8-ch alarm inputs
I/O output
2
TF card
Max to 32 G, SD 2.0 or lower version
Indoor station/General
Power supply
IEEE802.3af, standard PoE 12 VDC/1 A
Power consumption
≤ 7 W
Working temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working humidity
10% to 90%
Dimension (L x W x H)
180 mm × 140 mm × 22.4 mm (7.09" ×5.51" × 0.88")
Power supply via detector
12 V, 200 mA
Weight
899 g (with packaging) 355 g (without packaging)
